CONFIGURATION
| Specifications Of Performance | |||
| Operation Weight | 2000kg | Power | 15HP |
|---|---|---|---|
| Bucket Capacity | 0.04m³ | Engine Model | Kubota D722 |
| Operation Mode | Hydraulic Pilot | Travel Speed | 3km/h |
| Bucket Digging Force | 13.5KN | Bucket Arm Digging Force | 10.1KN |
| Transport Length | 2200mm | Chassis Width | 1160mm |
| Multi-Way Valve | Taifeng | Platform Rear Turning Radius | 930mm |
| Total Length Of Track | 1350mm | Platform Ground Clearance | 385mm |
| Main Dimension | |||
| Overall Dimensions | 2200*1100*2200mm | Track Gauge | 1060mm |
| Track Height | 320mm | Track Width | 230mm |
| Operating Range | |||
| Max Digging Radius | 3280mm | Min Radius Of Rotation | 1100mm |
| Max Digging Depth | 1850mm | Max Digging Height | 2790mm |
| Max Dumping Height | 2400mm | Max Vertical Digging Height | 1950mm |
| Max Lifting Height Of Dozer Blade | 270mm | Max Digging Depth Of Dozer Blade | 200mm |
Due to the continuous updating and progress of technology, any differences in technical parameters and configurations between the actual product and the actual product shall be subject to the actual product delivered; Additionally, the machine in the picture may include additional equipment.
Demo Video+Get More
Structural component optimization
Increased excavation power
The bucket excavation force is 16.9kn, and the shaking rod excavation force is 9.6kn, making the work more powerful
Standard hydraulic lock
Add hydraulic locks to the hydraulic oil circuit and deflection cylinder of the bulldozer to further increase cylinder settlement and improve customer satisfaction.
upgrades of Teeth Buckets & Boom Cylinders
teeth buckets installed by a horizontal pin for easy disassembly. to enlarge boom cylinders diameter to increase lifting power.
MY20 Multifaceted Expert
Deflectable device
The range of the deflectable working device is 625mm to the left and 400mm to the right. Both sides can easily dig to the outer edge of the track, and can work in narrow spaces with limited space such as walls and corners.
Telescopic walking frame
The adjustable width range of the retractable walking frame is 980mm~1350mm, which improves the stability of the entire machine and meets various working conditions.
Rotating bulldozer
The rotary plug-in bulldozer ensures passability, making it easy for the excavator to pass through less than 1m of working space and improving work efficiency.
MY20 small excavator is mainly suitable for
Broken road surface, Narrow bucket construction, Trench excavation,soil improvement, etc
Broken road surface, Narrow bucket construction, Trench excavation,soil improvement, etc
Company Info+Get More
EP Machinery Co., Ltd. since 1998, 1 factory, 1 company, more than 300 workers, 3000 square meters workshop, more than 16 years of export experience, we are a professional manufacturer of construction machinery in China, the machines cover wheel excavator 4-10 tons, small and large crawler excavator 1-10 tons, small compact excavator and small mini excavator, etc. So I believe there must be a model that can meet your needs. Most of the machines have CE, TUV certificates, company ISO certificates. Every year, more than 1000 mini excavators are sold to the European market, 500 to the Australian market, the United States, Canada market.
Selected FAQ+Get More
The excavation depth varies with the machine model. The excavation depth of small excavators is generally 1.6-3.8m.
The mini-excavator has powerful functions and can handle all kinds of work, such as digging holes, digging ditches, demolishing, removing tree stumps, digging garden ponds, etc.
The price of attachments varies depending on factors such as type, brand, model, etc., and generally ranges from a few hundred yuan to a few thousand yuan. When purchasing, choose products produced by regular manufacturers and avoid buying fake and shoddy products.
around 10,000 hours
Regularly check the connection and tightening of each component, and replace seriously worn components in a timely manner. When cleaning accessories, use special detergent and soft cloth to wipe them, and avoid using acid and alkali corrosive substances. Lubricating parts should be regularly filled with lubricating oil to maintain good lubrication.
When choosing, factors such as equipment stability, power, excavation depth, and after-sales service should be considered.
