CONFIGURATION
| Specifications Of Performance | |||
| Operation Weight | 5850kg | Climbing Ability | 70% |
|---|---|---|---|
| Bucket Capacity | 0.22m³ | Bucket Digging Force | 38.5kn |
| Travel Speed | 4.2/2.2km/h | Rotation Speed | 9.5r/min |
| Hydraulic Oil Tank Capacity | 80L | ||
| Track Length | 2560mm | Boom Length | 3000mm |
| Main Dimension | |||
| Operation Weight | 5850kg | Total Length Of Track | 2560mm |
| Counterweight Ground Clearance | 700mm | Transport Distance | 5960mm |
| Overall Height | 2690mm | Boom Length | 3000mm |
| Bucket Stick Length | 1630mm | Min Ground Clearance | 360mm |
| Track Length | 2560mm | ||
| Operating Range | |||
| Max Digging Height | 5750mm | Max Dumping Height | 3980mm |
| Max Digging Depth | 3860mm | Rear Turning Radius | 1700mm |
| Counterweight Height | 1685mm | ||
Due to the continuous updating and progress of technology, any differences in technical parameters and configurations between the actual product and the actual product shall be subject to the actual product delivered; Additionally, the machine in the picture may include additional equipment.
Demo Video+Get More
MY60 Mini Excavator is a brand new product of E.P Machinery Manufacturing Company's mini excavator series. Based on a thorough understanding of customer needs and integrating advanced international technology, it is a micro, tailless, tracked hydraulic excavator with independent property rights
MY60 hydraulic excavator has the characteristics of "high reliability, excellent performance, safety, environmental protection, comfort and convenience", and can be equipped with various configurations to meet the needs of different countries and customers
Reinforced structural components
The left and right beams of the X-shaped lower frame and box structure have high strength, high rigidity, and excellent bending and torsion resistance, which can meet the needs of different working conditions
The MY60 small excavator has a reinforced X-shaped box structure and an enlarged box section, which overall improves the strength of the lower frame and makes the entire machine work more stably
The MY60 small excavator uses supporting wheels instead of carrier rollers and adopts a bilateral installation method, which improves the stress conditions, makes the structure more sturdy, and significantly improves the service life of the carrier rollers
Due to the continuous updating and progress of technology, any differences in technical parameters and configurations between the actual product and the actual product shall be subject to the actual product delivered; Additionally, the machine in the picture may include additional equipment.
ENGINE
Hydraulic Valve
Piston Pump
Motor
- According To Customer Requirements, Engines Can Be Customized To Meet Different Operational Requirements Of Customers
- Customize A Complete Set Of Well-Known European Brand Hydraulic Systems To Ensure High Reliability Of The Hydraulic System
- Newly Designed Robust Structural Components With Longer Service Life
dynamical system
KOOP Engine
The MY60 small excavator is equipped with a 13.7kw koop engine, which has strong power and can ensure the reliability of the machine in harsh working conditions.
Kubota Engine
Equipped with a Kubota engine, with a power of up to 15.4kW, ensuring strong power output and reliability and durability.
Changchai Engine
Strong power, fuel economy, high reliability, environmental protection, energy-saving, and wide adaptability, it is an important component of the MY28 small excavator.
hydraulic system
Equipped with a load sensitive system, it has higher work efficiency, better handling performance, and superior flat performance. The main valve diameter increases, the pressure loss decreases, the valve body oil passage is optimized, the hydraulic power is reduced, and the overall operational energy efficiency is improved
Company Info+Get More
EP Machinery Co., Ltd. since 1998, 1 factory, 1 company, more than 300 workers, 3000 square meters workshop, more than 16 years of export experience, we are a professional manufacturer of construction machinery in China, the machines cover wheel excavator 4-10 tons, small and large crawler excavator 1-10 tons, small compact excavator and small mini excavator, etc. So I believe there must be a model that can meet your needs. Most of the machines have CE, TUV certificates, company ISO certificates. Every year, more than 1000 mini excavators are sold to the European market, 500 to the Australian market, the United States, Canada market.
Selected FAQ+Get More
Mini excavator is an ideal excavator to meet the daily work needs of workers. Its fuselage is only 72cm wide, with a foldable flip bar, which can pass through very narrow places and even reach the places that most people can reach.
The price of attachments varies depending on factors such as type, brand, model, etc., and generally ranges from a few hundred yuan to a few thousand yuan. When purchasing, choose products produced by regular manufacturers and avoid buying fake and shoddy products.
The maintenance of a small mini excavator is relatively simple. Regular inspection and replacement of necessary wearing parts can maintain its good working condition.
In fact, the design of small mini excavators focuses on simplicity, so that even non-professionals can master the basic operations in a short time.
Our E.P brand small mini excavator accessories have video instructions on how to use them. For details, please refer to 'Small Excavation Accessories'.
There are many types of attachments for small mini excavators, including buckets, grab buckets, wood clamps, digging buckets, breaker hammers, augers, bulldozer scrapers, hooks, etc.
