CONFIGURATION
| Specifications Of Performance | |||
| Operation Weight | 2780kg | Power | 30HP/22.1KW |
|---|---|---|---|
| Bucket Capacity | 0.1m³ | Engine Model | LaidongLL385B |
| Operation Mode | Backhoe | Grade Ability | 35°(58%) |
| Hydraulic Pump | Piston Pump | Travel Speed | 3km/h |
| Main Dimension | |||
| Overall Dimensions | 3510*1380*2400mm | Min Ground Clearance | 530mm |
| Boom Swing | 45°Right/85°Left | Track Width | 230mm |
| Operating Range | |||
| Max Digging Depth | 2630mm | Max Ground Clearance Of Dozer Blade | 500mm |
| Max Digging Radius | 4300mm | Max Digging Height | 3914mm |
| Max Dumping Height | 2588mm | Min Swing Radius | 1520mm |
| Track Width | 230mm | Track Length | 1790mm |
Due to the continuous updating and progress of technology, any differences in technical parameters and configurations between the actual product and the actual product shall be subject to the actual product delivered; Additionally, the machine in the picture may include additional equipment.
dynamical system
The all-new MY30 offers three power options: Kubota, Briggs&Stratton, and Kepu, with precise fuel injection technology to ensure excellent power and economy
Kubota Engine
Koop Engine
Briggs & Stratton Enginee
hydraulic system
The MY30 small excavator is equipped with well-known hydraulic components and independently developed constant power algorithms, achieving efficient matching of engines, pumps, and valves, and significantly improving the overall energy efficiency of the entire machine operation.
The MY30 small excavator adopts a high torque walking motor with strong power, effectively improving the walking traction force.
Demo Video+Get More
Company Info+Get More
EP Machinery Co., Ltd. since 1998, 1 factory, 1 company, more than 300 workers, 3000 square meters workshop, more than 16 years of export experience, we are a professional manufacturer of construction machinery in China, the machines cover wheel excavator 4-10 tons, small and large crawler excavator 1-10 tons, small compact excavator and small mini excavator, etc. So I believe there must be a model that can meet your needs. Most of the machines have CE, TUV certificates, company ISO certificates. Every year, more than 1000 mini excavators are sold to the European market, 500 to the Australian market, the United States, Canada market.
Selected FAQ+Get More
Regularly check the connection and tightening of each component, and replace seriously worn components in a timely manner. When cleaning accessories, use special detergent and soft cloth to wipe them, and avoid using acid and alkali corrosive substances. Lubricating parts should be regularly filled with lubricating oil to maintain good lubrication.
There are many types of attachments for small mini excavators, including buckets, grab buckets, wood clamps, digging buckets, breaker hammers, augers, bulldozer scrapers, hooks, etc.
Mini excavator is an ideal excavator to meet the daily work needs of workers. Its fuselage is only 72cm wide, with a foldable flip bar, which can pass through very narrow places and even reach the places that most people can reach.
When choosing, factors such as equipment stability, power, excavation depth, and after-sales service should be considered.
The mini-excavator has powerful functions and can handle all kinds of work, such as digging holes, digging ditches, demolishing, removing tree stumps, digging garden ponds, etc.
First of all, it depends on the materials that need to be processed. If you need to dig out sand, gravel, etc., you can choose a bucket or breaker; if you need to transport wood, steel, etc., you can choose wood clamps or hooks; if you need to compact the ground Or piling, you can choose a tamping attachment or an auger.
