CONFIGURATION

Performance Parameter	Unit	Specification
Bucket Capacity	M³	0.26
Climbing Ability		35°
Max Digging Force	N	5560
Travel Speed	KM/H	≤20
Unit Swing Speed	R/Min	8-10
Oil Tank Volume	L	22
Working Range	Unit	SPecification
Max Digging Height	MM	4650
Max Digging Depth	MM	2545
Max Dumping Height	MM	3050
Max Digging Radius	MM	4630
Max Lifting Height Of Dozer Blade	MM	359
Max Digging Depth Of Dozer Blade	MM	268
Dimensions	Unit	Specification
Operation Weight	KG	3600
Transport Distance	MM	4400
Total Height	MM	2450
Chassis Width	MM	1530/1600
Track Gauge	MM	1230
Boom Length	MM	2400
Bucket Stick Length	MM	1250
Dynamical System	Unit	Specification
Model		LaiDong490
Power	KW	34
Cooling Method		Water-cooling

Demo Video+Get More

Company Info+Get More

EP Machinery Co., Ltd. since 1998, 1 factory, 1 company, more than 300 workers, 3000 square meters workshop, more than 16 years of export experience, we are a professional manufacturer of construction machinery in China, the machines cover wheel excavator 4-10 tons, small and large crawler excavator 1-10 tons, small compact excavator and small mini excavator, etc. So I believe there must be a model that can meet your needs. Most of the machines have CE, TUV certificates, company ISO certificates. Every year, more than 1000 mini excavators are sold to the European market, 500 to the Australian market, the United States, Canada market.

EP Machinery, a professional manufacturer of small excavators in China

small mini excavator workshop

Selected FAQ+Get More

First of all, it depends on the materials that need to be processed. If you need to dig out sand, gravel, etc., you can choose a bucket or breaker; if you need to transport wood, steel, etc., you can choose wood clamps or hooks; if you need to compact the ground Or piling, you can choose a tamping attachment or an auger.

When choosing, factors such as equipment stability, power, excavation depth, and after-sales service should be considered.

In fact, the design of small mini excavators focuses on simplicity, so that even non-professionals can master the basic operations in a short time.

The excavation depth varies with the machine model. The excavation depth of small excavators is generally 1.6-3.8m.

Regularly check the connection and tightening of each component, and replace seriously worn components in a timely manner. When cleaning accessories, use special detergent and soft cloth to wipe them, and avoid using acid and alkali corrosive substances. Lubricating parts should be regularly filled with lubricating oil to maintain good lubrication.

Our E.P brand small mini excavator accessories have video instructions on how to use them. For details, please refer to 'Small Excavation Accessories'.
